How to Create a New Module in Odoo

Step-by-Step: How to Create an Odoo Module

Follow these concrete technical steps to build, configure, secure, and install your custom module.

Step 1: Create the Module Skeleton

Instead of creating directories and files manually, use Odoo's built-in scaffold CLI tool to generate the standard module structure:

./odoo-bin scaffold my_module /path/to/custom/addons

This creates a pre-configured directory named my_module inside your custom addons directory, complete with models, views, controllers, and demo data.

Step 2: Module Folder Structure

A streamlined, complete custom module contains the following files:

my_module/
├── __init__.py
├── __manifest__.py
├── models/
│   ├── __init__.py
│   └── models.py
├── security/
│   └── ir.model.access.csv
└── views/
    └── views.xml

Step 3: Define the Manifest (__manifest__.py)

The manifest file declares your module's metadata, its dependencies, and the data files that Odoo loads upon installation.

Here is a minimal, clean __manifest__.py:

# -*- coding: utf-8 -*-
{
    'name': 'My Custom Module',
    'version': '18.0.1.0.0',
    'summary': 'Manage custom business records in Odoo',
    'sequence': 10,
    'category': 'Customizations',
    'depends': ['base'],
    'data': [
        'security/ir.model.access.csv',
        'views/views.xml',
    ],
    'installable': True,
    'application': True,
    'license': 'LGPL-3',
}

Ensure your root __init__.py imports the models directory:

# -*- coding: utf-8 -*-
from . import models

Step 4: Create a Data Model (models/models.py)

Odoo models represent database tables, mapping Python classes directly to PostgreSQL tables through Odoo's ORM. Here is a simple model with two fields:

# -*- coding: utf-8 -*-
from odoo import models, fields

class MyCustomModel(models.Model):
    _name = 'my_module.custom_model'
    _description = 'My Custom Model'

    name = fields.Char(string='Title', required=True)
    description = fields.Text(string='Description')

Also ensure models/__init__.py imports your model file:

# -*- coding: utf-8 -*-
from . import models

Step 5: Add Security Access (security/ir.model.access.csv)

In Odoo, any model defined in Python is hidden by default. Without an explicit access control list (ACL) rule in security/ir.model.access.csv, even system administrators cannot view, create, or modify records.

id,name,model_id:id,group_id:id,perm_read,perm_write,perm_create,perm_unlink
access_my_module_custom_model_user,my_module.custom_model.user,model_my_module_custom_model,base.group_user,1,1,1,1

model_my_module_custom_model is the auto-generated XML ID for your model (with underscores replacing dots in _name). 1,1,1,1 grants full read, write, create, and delete permissions to standard internal users.

Step 6: Define Views and Menus (views/views.xml)

Views describe the user interface. We'll create a list view, a form view, a window action, and top-level navigation menus in views/views.xml:

<?xml version="1.0" encoding="utf-8"?>
<odoo>
    <!-- List View (Odoo 18 uses <list>; earlier versions use <tree>) -->
    <record id="view_my_module_list" model="ir.ui.view">
        <field name="name">my_module.custom_model.list</field>
        <field name="model">my_module.custom_model</field>
        <field name="arch" type="xml">
            <list string="Custom Records">
                <field name="name"/>
                <field name="description"/>
            </list>
        </field>
    </record>

    <!-- Form View -->
    <record id="view_my_module_form" model="ir.ui.view">
        <field name="name">my_module.custom_model.form</field>
        <field name="model">my_module.custom_model</field>
        <field name="arch" type="xml">
            <form string="Custom Record">
                <sheet>
                    <group>
                        <field name="name"/>
                        <field name="description"/>
                    </group>
                </sheet>
            </form>
        </field>
    </record>

    <!-- Window Action -->
    <record id="action_my_module_records" model="ir.actions.act_window">
        <field name="name">Custom Records</field>
        <field name="res_model">my_module.custom_model</field>
        <field name="view_mode">list,form</field>
    </record>

    <!-- Menu Items -->
    <menuitem id="menu_my_module_root" name="My Module" sequence="10"/>
    <menuitem id="menu_my_module_records" name="Records" parent="menu_my_module_root" action="action_my_module_records" sequence="10"/>
</odoo>

Step 7: Install the Module in Odoo

To make your module available in the web interface:

1. Add your custom addons directory to addons_path in your odoo.conf:

   addons_path = /opt/odoo/odoo/addons,/path/to/custom/addons

2. Restart your Odoo server instance:

   sudo systemctl restart odoo

3. Open Odoo in your browser, go to Settings, and click Activate the developer mode.
4. Go to the Apps menu, click Update Apps List in the top navigation bar, and confirm the update.
5. Clear the "Apps" filter in the search box, search for My Custom Module, and click Activate (or Install).

Step 8: Upgrade After Making Changes

As you develop, you will update Python models and modify XML views. To apply changes without reinstalling the module, restart Odoo with the -u flag:

./odoo-bin -c odoo.conf -u my_module -d mydb

This command reloads Python code, updates the database schema, and refreshes XML view definitions in one pass.

Need a Custom Module Built?

Scaffolding a simple module is straightforward, but production ERP applications often require complex business logic, third-party API synchronizations, automated accounting flows, and rigorous testing across versions. Our team of certified developers can architect, build, and support enterprise-grade modules tailored precisely to your workflows. Learn more about our Odoo development services.

Frequently Asked Questions

What is the difference between an Odoo module and an app?

In Odoo, every app is a module, but not every module is an "app". A standalone app provides major business capabilities (such as CRM, Invoicing, or Inventory) and sets 'application': True in its manifest. A regular module is typically a technical plugin, bridge, or workflow extension that has 'application': False, adding features to existing apps without cluttering the main app dashboard.

Can I build a module without coding (Odoo Studio)?

Yes, Odoo Enterprise includes Odoo Studio, a low-code tool that enables users to add custom fields, customize form views, and build basic automated actions through a graphical user interface. However, for complex business rules, multi-table queries, version-controlled codebases, and custom integrations, developing a Python-based module is the recommended approach.

How do I upgrade a custom module to a new Odoo version?

Upgrading a custom module to a newer Odoo release involves auditing deprecated ORM methods, updating XML view tags (such as transitioning from <tree> to <list> in Odoo 18), updating JavaScript OWL web components, and testing data migrations. If your team is planning an upgrade and needs assistance modernizing legacy custom modules, explore our Odoo migration services.
